Technology Articles

2023-04 Semiconductors Texas Instruments

[四月 13 2023] The Texas Instruments TMUX8108/TMUX8109 multiplexer is a modern high voltage analog multiplexer in 8:1(single ended) and 4:1(differential) configurations. The device works well with dual, single or asymmetric power supplies, and the maximum supply voltage is up to 100V. The TMUX810x device provides consistent analog parametric performance across the entire power supply voltage range. The TMUX8108 ...

2023-04 Semiconductors STMicroelectronics

[四月 13 2023] The STMicroelectronics ST4SIM-200M eSIM GSMA System-on-Chip (SoC) is designed to manage various MNO profiles and ensure that all eSIM stakeholders have the appropriate level of security. Stakeholders include users, Mnos, Oems, hardware integrators and service providers. This SoC can contain an embedded security element to store credentials and/or stand-alone applications managed directly by an MC ...

2023-04 Semiconductors Microchip Technology

[四月 13 2023] The LX34070 inductive position sensor is an analog front-end interface integrated circuit used to control an external LC oscillator. Here, the inductance (L) of the external slot circuit is the main coil of the inductance sensor formed by the trace on the printed circuit board (PCB). The signal generated by the two magnetically coupled secondary coils is the analog position input signal of the LX ...

2023-04 Semiconductors TDK

[四月 13 2023] TDK's CLT32 series of power inductors are compact in size and offer excellent electrical value. Nine models have inductance ranges from 17 nH to 440 nH and are designed for saturation currents from 13.5 A to 60 A. The compact footprint of 3.2 mm x 2.5 mm and insertion height of 2.5 mm make these SMT power inductors very compact. They are designed for temperatures ranging from -40°C to +165°C, inc ...

2023-04 Sensors TDK-Lambda

[四月 13 2023] The TDK-Lambda RGA series of non-isolated DC-DC step-down converters provide power ratings of up to 250W with wide 9V to 40V or 9V to 53V input ranges for up to 98% efficiency. These converters are packaged in a five-sided aluminum housing and have an extensive output adjustment range, allowing one model to be used in multiple locations, assisting with inventory and part count reduction. The modu ...

2023-04 Power Texas Instruments

[四月 13 2023] Texas Instruments ISOW7721 Dual channel digital isolator is an electrical isolation digital isolator with an integrated high efficiency power converter and low emissions. The integrated DC-DC converter provides isolated power up to 550mW. This feature eliminates the need for a separate isolated power source in space-constrained isolation designs. If additional power is needed, Texas Instruments' ...

2023-04 Semiconductors Allegro MicroSystems, LLC

[四月 13 2023] The Allegro MicroSystems A8511 Multi-output WLED/RGB Driver is a fully integrated high brightness (HB) LED driver solution for medium sized backlit displays. The flexible A8511 drive does not require an external power device to complete the backlight design standard. The A8511 integrates FETs for boost converters and four 150mA current receivers, providing a complete integrated solution at HB LED ...

2023-04 Semiconductors Texas Instruments

[四月 12 2023] Texas Instruments SN75LVPE5412 is a four-channel linear heavy driver with integrated multiplexer (demux). Low power high performance linear redrive design supports PCIe 5.0 and other interfaces up to 32 Gbps. The SN75LVPE5412 receiver uses a continuous time linear equalizer (CTLE) to provide high frequency gain. Equalizer can open a completely closed input eye due to inter-symbol interference (IS ...

2023-04 Connectors Taitien

[四月 12 2023] Taitien's SC-cut or stress compensation crystals are the best choice for applications using oven controlled crystal oscillators and high temperature oscillators because of their lower sensitivity to mechanical and thermal stress and vibration. Taitien's high precision sc cut quartz crystal resonators utilize the company's in-house production of high q sc cut wafer design. They are ideal for trans ...

2023-04 Semiconductors Texas Instruments

[四月 12 2023] The Texas Instruments TPSM63604 Synchronous Stepdown Power Module is a highly integrated 36V, 4A DC/DC solution that combines power MosFEts, shielded inductors and passives in the enhanced HotRod QFN package. The module has V(IN) and V(OUT) pins located at the corners of the package to optimize input and output capacitance placement. Four larger heat pads below the module make the layout simple a ...

2023-04 Power Omron Electronics Inc-EMC Div

[四月 12 2023] Omron's ultra-thin relays offer a variety of advantages, from providing better visibility and vibration resistance to being the fastest switching relay (solid-state version) in the industry. These relays are easier to install, operate, and maintain than other solutions. They are 6.2 mm wide, provide fast switching speeds for PLC output, and have mechanical and solid-state options that add value t ...

2023-04 Semiconductors Rohm Semiconductor

[四月 12 2023] ROHM's BD14210G-LA current detection amplifier guarantees long term support for the industrial market. The device works on a single 2.7V to 5.5V power supply. It has a wide common-mode voltage range of -0.2V to +26 V, outputs analog voltage and gains of 20 V/V. The matched gain resistance minimizes the gain error and achieves low bias voltage. Under typical conditions, the input bias current is 1 ...
