Technology Articles

2023-04 Semiconductors TDK

[四月 13 2023] TDK's CLT32 series of power inductors are compact in size and offer excellent electrical value. Nine models have inductance ranges from 17 nH to 440 nH and are designed for saturation currents from 13.5 A to 60 A. The compact footprint of 3.2 mm x 2.5 mm and insertion height of 2.5 mm make these SMT power inductors very compact. They are designed for temperatures ranging from -40°C to +165°C, inc ...

2023-04 Sensors TDK-Lambda

[四月 13 2023] The TDK-Lambda RGA series of non-isolated DC-DC step-down converters provide power ratings of up to 250W with wide 9V to 40V or 9V to 53V input ranges for up to 98% efficiency. These converters are packaged in a five-sided aluminum housing and have an extensive output adjustment range, allowing one model to be used in multiple locations, assisting with inventory and part count reduction. The modu ...

2023-04 Power Omron Electronics Inc-EMC Div

[四月 12 2023] Omron's ultra-thin relays offer a variety of advantages, from providing better visibility and vibration resistance to being the fastest switching relay (solid-state version) in the industry. These relays are easier to install, operate, and maintain than other solutions. They are 6.2 mm wide, provide fast switching speeds for PLC output, and have mechanical and solid-state options that add value t ...

2023-04 Semiconductors Rohm Semiconductor

[四月 12 2023] ROHM's BD14210G-LA current detection amplifier guarantees long term support for the industrial market. The device works on a single 2.7V to 5.5V power supply. It has a wide common-mode voltage range of -0.2V to +26 V, outputs analog voltage and gains of 20 V/V. The matched gain resistance minimizes the gain error and achieves low bias voltage. Under typical conditions, the input bias current is 1 ...

2023-04 Connectors Taitien

[四月 12 2023] Taitien's SC-cut or stress compensation crystals are the best choice for applications using oven controlled crystal oscillators and high temperature oscillators because of their lower sensitivity to mechanical and thermal stress and vibration. Taitien's high precision sc cut quartz crystal resonators utilize the company's in-house production of high q sc cut wafer design. They are ideal for trans ...

2023-04 Semiconductors Texas Instruments

[四月 12 2023] The Texas Instruments TPSM63604 Synchronous Stepdown Power Module is a highly integrated 36V, 4A DC/DC solution that combines power MosFEts, shielded inductors and passives in the enhanced HotRod QFN package. The module has V(IN) and V(OUT) pins located at the corners of the package to optimize input and output capacitance placement. Four larger heat pads below the module make the layout simple a ...

2023-04 Semiconductors Texas Instruments

[四月 12 2023] Texas Instruments SN75LVPE5412 is a four-channel linear heavy driver with integrated multiplexer (demux). Low power high performance linear redrive design supports PCIe 5.0 and other interfaces up to 32 Gbps. The SN75LVPE5412 receiver uses a continuous time linear equalizer (CTLE) to provide high frequency gain. Equalizer can open a completely closed input eye due to inter-symbol interference (IS ...

2023-04 Semiconductors Infineon Technologies

[四月 11 2023] The built-in energy capture capability of sensor controllers based on near field communication (NFC) technology is crucial to the development of passive smart devices. This feature not only makes it easier to design smart devices for iot, so that they can be used in a wide range of applications, but also makes the devices work more accurately and efficiently. Infineon Technologies' latest NGC1081 ...

2023-04 Power Diodes Incorporated

[四月 11 2023] Diodes bring out the AP7387Q low voltage difference (LDO) voltage regulator. The device provides a maximum output current of 150mA, with a wide input voltage ranging from 5V to 60V, and a voltage difference of 700mV (typical value) at 100mA output current. The device provides engineering teams with an easy-to-implement point-of-load (PoL) solution for automotive audio, navigation, taillight, tran ...

2023-04 Power Diodes Incorporated

[四月 11 2023] Diodes announced new two-way transient Voltage suppressors (TVS) diodes to meet the market demand for proper protection of high speed data ports. D3V3Z1BD2CSP to meet the protection of electrostatic discharge (ESD) shock and spike events. The main applications of this product are high performance computing hardware, I/O ports for smartphones, laptops and tablets, monitors and game consoles. While ...

2023-04 Semiconductors NXP

[四月 11 2023] SLN-VIZN3D-IOT Face recognition development kit from NXP Semiconductors. With SLN-VIZNAS-IOT, developers are able to quickly and easily add facial recognition and 3D live detection capabilities to their products, particularly suited to the smart home and security sectors. The NXP SLN-VIZN3D-IOT development suite combines a high-performance 3D structured optical module (SLM) camera with an i.MX RT ...

2023-04 Power Toshiba Semiconductor and Storage

[四月 11 2023] Toshiba Electronic components and storage Devices Corporation announced the launch of 150V N channel power MOSFET- "TPH9R00CQ5", which uses the latest generation of U-MOSX-H process, can be used for industrial equipment switching power supply, including data centers and communication base stations and other power applications. TPH9R00CQ5 has the industry-leading 9.0mΩ (maximum) low drain-source o ...
