Technology Articles

2023-04 Sensors TDK-Lambda

[四月 7 2023] TDK Lambda's CCG1R5 (1.5W) and CCG3 (3W) components can be operated at full load in the temperature range of -40°C to +85°C under convection-cooled conditions. These models consist of 36 voltage and current combinations and have 3.3V, 5 V, 12 V, 15 V and dual ±12 V and ±15 V outputs. Dual output models can also be connected to 24 V and 30 V power supplies. They can all operate at 4.5 V to 18 V, 9 ...

2023-04 Sensors ABB Embedded Power

[四月 3 2023] ABB Embedded Power's MLX and SLX series modules operate over a wide input voltage range from 7 VDC to 14 VDC, providing PMBus programmable output voltages from 0.45 VDC to 2.0 VDC. The DLynx III power module features an advanced PID-based adjustable digital control loop that helps ensure loop stability, provides fast transient response, and reduces output capacitance requirements. Additional SLX ...

2023-04 Power KEMET

[四月 3 2023] KEMET's full range of axial and radial coronal capacitors for automotive applications includes the Ultra High CV PEG227 and PEH227 series. KEMET's capacitors have excellent electrical performance and high energy storage capacity. They are rated for temperatures ranging from -40°C to +125°C or -40°C to +150°C at derated voltages. The series uses a polarized all-welded design with tinned copper lea ...

2023-04 Power KEMET

[四月 3 2023] KEMET's C700 safety rated disk capacitors are designed for interference suppression AC line filtering applications. These capacitors have internationally recognized safety certifications and are ideal for applications that need to keep potentially destructive or destructive line transients and EMI away from sensitive equipment. They are also an ideal solution when line interference needs to be su ...

2023-04 Power Renesas Electronics America

[四月 3 2023] Renesas's RAA271082 multitrack power supply IC features one primary high voltage synchronous step-down regulator, two secondary low voltage synchronous step-down regulators, and one LDO regulator. It provides four overvoltage (OV) and undervoltage (UV) monitors, I2C communications, a universal I/O pin and a dedicated reset output/failure indicator. A 4 mm x 4 mm 24 pin step cut QFN (SCQFN) packag ...

2023-04 Power XP Power

[四月 3 2023] XP Power's ASB160 Series low-profile, all-brick, baseboard cooled AC/DC power supply requires no external components. The series includes built-in EMC filters, AC fuses, and mass storage capacitors to provide complete AC/DC power solutions that can be installed in industrial and semiconductor manufacturing applications. The ASB160 series reduces the failure rate through effective heat dissipation ...

2023-04 Sensors Phoenix Contact

[四月 3 2023] Phoenix Contact's LPTA 16 series provides a tool-free lever connection technology ideal for field device connections. The consistent PCB terminal block product line combines lever-driven high ease of use with reliable insertion spring connections. In the growing market for renewable energy, electric drives, and electric charging infrastructure, drives need to be connected quickly and securely. Fe ...

2023-03 Semiconductors Analog Devices

[三月 23 2023] The AD8345 is a silicon RFIC orthogonal modulator designed for use from 140 MHz to 1000 MHz. 16 pin TSSOP_EP package. Its performance is specified in the temperature range −40°C to +85°C. Its superior phase accuracy and amplitude balance enable high performance direct modulation of intermediate frequency carriers. The AD8345 accurately splits the external LO signal into two orthogonal components ...

2023-03 Power Texas Instruments

[三月 23 2023] The TL317 is an adjustable three-pole voltage regulator capable of delivering 100 mA in the 1.25V to 32V output voltage range. It is very easy to use and only requires two external resistors to set the output voltage. The regulator provides complete overload protection and is only available in integrated circuits. Current limiting and thermal overload protection are included on the chip. All over ...

2023-03 Power Texas Instruments

[三月 23 2023] The LM613 consists of a dual operational amplifier, a dual comparator, and a programmable reference voltage in a 16-pin package. Op-amps are superior to most single-power op-amps by providing higher speeds and bandwidths as well as lower supply currents.The LM613 is a space-saving alternative to single-chip multi-chip solutions, providing a high level of integration without sacrificing performanc ...

2023-03 Semiconductors ON Semiconductor

[三月 23 2023] The NB4N1158 is a high performance 3.3V serial link replicator packaged in 4.7mm x 9.7mm TSSOP-28, providing serial loop replication and serial loopback control capabilities commonly required in Fibre Channel, GbE, HDTV and SATA applications. Other popular applications include host bus adapters for routing between internal and external connectors, and hot swap links between redundant switch fabri ...

2023-03 Power Texas Instruments

[三月 23 2023] The UC3853 provides simple and high performance active power factor correction. Using the same control technology as the UC1854, the 8-pin device utilizes a simplified architecture and internal oscillator to minimize the number of external components. The UC3853 integrates a precision multiplier/square/divider circuit, voltage and current loop error amplifiers, and a precision voltage reference f ...
